Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S4
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model: |
A1S4 |
Transaxle:: |
Italy Graziano Alex |
Range:: |
70-90KM |
Motor:: |
ADC 48V 3.7KW |
Warranty:: |
1 Year |
Body Color:: |
White Or Based On Panton Number |
Logo: |
Customized |
Controller:: |
48V/350A Curtis Conroller |
Model: |
A1S4 |
Transaxle:: |
Italy Graziano Alex |
Range:: |
70-90KM |
Motor:: |
ADC 48V 3.7KW |
Warranty:: |
1 Year |
Body Color:: |
White Or Based On Panton Number |
Logo: |
Customized |
Controller:: |
48V/350A Curtis Conroller |
Performance
| System | DC system | AC system |
| Passenger Capacity | 6 | 6 |
| Climbing capacity(full load) | 20% | 25% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 60-80km | 80-100km |
| Charging time | 8-10 hours | 8-10 hours |
| Max. loading weight | 360kgs | 360kgs |
| Min. turning radius | 2.9m | 2.9m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
Product Description
| Battery | 6*8V 275AH Trojan T-875 | ||
| Power of Motor | 48V 3700W | ||
| Controller | American Curtis Electronics Controller | ||
| Accelerator | Adjustable Inductive Accelerator Continuously Variable Speed System | ||
| Transaxle | Italy Graziano axle | ||
| Charger | Intelligent Onbaord Charger | ||
| Chassis configuration | |||
| Front-Suspension | Independent Spring Front Suspension | ||
| Rear-Suspension | Spring Hydraulic Shock Absorbers | ||
| Steering | Dual Self Adjusting "Rack&Pinion" Steetring | ||
| Brakes | Rear Wheel Mechanical Drum Brake and Regeneration Brake | ||
Electric System
| Item | Description |
| Lights |
48V, LED headlight (includes turning light and position light), LED taillights (includes brake lights and turning light), |
| Horn | Electric horn, 48V |
| Reverse buzzer | Electric, 48V |
| Combination switch | Control the lights and horn |
| Digital Meter (optional) | Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock |
