Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1H2/LC
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model:: |
A1H2/LC |
Seats:: |
2 Seats |
Max.Forward Speed:: |
24KM/H |
Ground Clearance:: |
114mm |
Wheelbase:: |
2300mm |
Body Cover:: |
PP Engineering Plastic |
Range:: |
50-70KM |
Min.Turning Radius:: |
3.6M |
Color:: |
Customized |
Dimension:: |
3400/1200/1800MM |
Model:: |
A1H2/LC |
Seats:: |
2 Seats |
Max.Forward Speed:: |
24KM/H |
Ground Clearance:: |
114mm |
Wheelbase:: |
2300mm |
Body Cover:: |
PP Engineering Plastic |
Range:: |
50-70KM |
Min.Turning Radius:: |
3.6M |
Color:: |
Customized |
Dimension:: |
3400/1200/1800MM |
| CONFIGURATION | |
| MOTOR: | ADC AC EXCITED MOTOR 48V 5KW |
| CONTROLLER: | CURTIS CONTROLLER 48V 350A(AC) |
| BATTERIES: | 48V Lithium |
| CHARGER: | 48V 17A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | SPECIAL AXLE FOR ELECTRIC VEHICLE |
| BRAKE SYSTEM: | REAR SELF-ADJUSTING DRUM BRAKE |
| STEERING SYSTEM: | DUAL SELF-ADJUSTING RACK & PINION |
| F/R SUSPENSION: | MCPHERSON INDEPENDENT SPRING SUSPENSION |
| TYRE: | 205/50-10 TYRE |
Performance
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 2 | 2 |
| Climbing capacity(full load) | 30% | 35% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 70-90km | 80-90km |
| Horn | Electric horn, 48V |
| Reverse buzzer | Electric, 48V |
| Combination switch | Control the lights and horn |
| Digital Meter (optional) | Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock |
Packing & Shipping
Excar golf cart will be packed in steel crate
| Model | Dimension(mm) | 20” container | 40” container | |||
| A1S2 | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield |
| 2641*1219*1727 | 2641*1219*1250 | 4 units | 8units | 10units | 20units |
|
Option Accessories
| Item | Option description | Item | Option description |
| 1 | E-key | 11 | 2-point seatbelt |
| 2 | Hinged windshield | 12 | Battery water refill system |
| 3 | Laminated windshield with wiper | 13 | Digital meter |
| 4 | Steel brush guard | 14 | EM brake |
| 5 | Front steel basket | 15 | Four wheel disc brake |
| 6 | Inner rear view mirror | 16 | Carlisle 205/50-10 tyre with10inch wheel |
| 7 | Side rear view mirror | 17 | Ice box |
| 8 | Enclosure | 18 | Sand bottle |
| 9 | Sunshine cover | 19 | Sand rake |
| 10 | Golf bag cover | 20 | Ball washer |
Color options
※ Body Color:White,Black,Beige,Champagene,Dark Green,Red,Metallic Red,Purple,Yellow,Green,Pink,Blue,Dark Blue or made on Pantone number
※ Seat Color:Black or Beige
※ Roof Color:Black,White or Beige
a) LCL shipment Packing:
roof move-off packing, steel frame , cartoon paper cover.
b)FCL shipment Packing:
packed by plastic foam & plastic film
