Dongguan Excar Electric Vehicle Co., Ltd salescn@excar.com.cn 86--13546943585
Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: M1S6
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model: |
M1S6 |
Ground Clearance: |
114MM |
Dimension: |
3900*1200*1900MM |
Min.Turning Radius: |
5.1M |
Pay Load: |
500KG |
Chassis: |
Steel Chassis |
Range: |
50-70KM |
Max.Forwarding Speed: |
25KM/H |
Model: |
M1S6 |
Ground Clearance: |
114MM |
Dimension: |
3900*1200*1900MM |
Min.Turning Radius: |
5.1M |
Pay Load: |
500KG |
Chassis: |
Steel Chassis |
Range: |
50-70KM |
Max.Forwarding Speed: |
25KM/H |
Features
1. Global Special LED Headlight
2. Efficient Italy graziano driving axle
3.FR/disc RR/drum, safety golf cart’s higher driving ability
4.Advanced Disc Brake Technology
5.USA Imported Unique E-KEY
6.100% Waterproof accelerator
7.Golf cart, sightseeing car, classic car, patrol car, housekeeping car, cargo car, utility car, security series
8.Special Design Battery Tray
9.Deep Cup Holders
10.Curtis Controller 48V 275A
11.Rear View Mirror And Driver/Passenger Side Mirrors
12.Automotive Safty Glass Windshield
| CONFIGURATION | |
| MOTOR: | EXCAR 48V 5KW(AC) |
| CONTROLLER: | EXCAR 48V/350A AC CONTROLLER |
| BATTERIES: | 48V |
| CHARGER: | 48V 17A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | SPECIAL REAR AXLE FOR ELECTRIC VEHICLE |
| BRAKE SYSTEM: | REAR SELF-ADJUSTING DRUM BRAKE |
| STEERING SYSTEM: | DUAL SELF-ADJUSTING RACK & PINION |
| F/R SUSPENSION: | MCPHERSON INDEPENDENT SPRING SUSPENSION |
Option Accessories
| Item | Option description | Item | Option description |
| 1 | E-key | 11 | 2-point seatbelt |
| 2 | Hinged windshield | 12 | Battery water refill system |
| 3 | Laminated windshield with wiper | 13 | Digital meter |
| 4 | Steel brush guard | 14 | EM brake |
| 5 | Front steel basket | 15 | Four wheel disc brake |
| 6 | Inner rear view mirror | 16 | Carlisle 205/50-10 tyre with10inch wheel |
| 7 | Side rear view mirror | 17 | Ice box |
| 8 | Enclosure | 18 | Sand bottle |
| 9 | Sunshine cover | 19 | Sand rake |
| 10 | Golf bag cover | 20 | Ball washer |
FAQ
1.Can you customize the cart according to our special request?
Yes,we can customize the cart according to your request unless some complex parts we hard to make.
2.What is your MOQ?
You can order just 1 unit .But if your order is big, we will provide you with a discount.
3.Can we put the Logo we designed on the cart?
Yes, you can put your own Logo on the cart.
4.What is your lead time for production?
The typical lead time of our cart is 15 days.
5.What kind of warranty Excar provides?
Non-artificial damaged products,shifting for a year or one year repair.
Dongguan Excellence Golf & Sightseeing Car Co.,ltd
