Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S4
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model NO.:: |
A1S4 |
Gradeability:: |
20-30% |
Battery:: |
USA Trojan T-875 6*8V |
Voltage Of Battery:: |
48V |
Maximum Speed:: |
20-30 Km/h |
Transaxle:: |
Italy Graziano Axle |
Certification:: |
CE, ISO |
Suitable For:: |
Golf Course, Tourist Area,Holiday Village |
Model NO.:: |
A1S4 |
Gradeability:: |
20-30% |
Battery:: |
USA Trojan T-875 6*8V |
Voltage Of Battery:: |
48V |
Maximum Speed:: |
20-30 Km/h |
Transaxle:: |
Italy Graziano Axle |
Certification:: |
CE, ISO |
Suitable For:: |
Golf Course, Tourist Area,Holiday Village |
Basic specification
Golf cart had become one of our major products in the recent years.
This type of golf cart is becoming more and more popular, and we're selling very well over the country.
1. Global Special LED Headlight
2. Efficient Italy graziano driving axle
3. FR/disc RR/drum, safety golf cart’s higher driving ability
4. Advanced Disc Brake Technology
5. USA Imported Unique E-KEY
6.100% Waterproof accelerator
7. Golf cart, sightseeing car, classic car, patrol car, housekeeping car, cargo car, utility car, security series
8. Special Design Battery Tray
9. Deep Cup Holders
Feature of Golf Car
| Battery | 6*8V 275AH Trojan T-875 | ||
| Power of Motor | 48V 3700W | ||
| Controller | American Curtis Electronics Controller | ||
| Accelerator | Adjustable Inductive Accelerator Continuously Variable Speed System | ||
| Transaxle | Italy Graziano axle | ||
| Charger | Intelligent Onbaord Charger | ||
| Chassis configuration | |||
| Front-Suspension | Independent Spring Front Suspension | ||
| Rear-Suspension | Spring Hydraulic Shock Absorbers | ||
| Steering | Dual Self Adjusting "Rack&Pinion" Steetring | ||
| Brakes | Rear Wheel Mechanical Drum Brake and Regeneration Brake | ||
| Performance | |||
| Max Speed | 25 km/h | Chassis | Aluminum |
| Max Travel Distance | 70-90km | Wheelbase | 2490mm |
| Slope Climbing Capacity | 30% | Front Wheel Tread | 860mm |
| Brake Range | ≤3m | Rear Wheel Tread | 970mm |
| Max Noise | <50dB | Tires | 205/50-10 |
| Carrying Capacity | 600KG | Dimension | 3200*1200*1900mm |
| Turning Radius | 2900mm | Passengers | 4 Person |
| Net Weight | 430kg | Ground Clearance | 124mm |
Option Accessories
To increase the sales value of our golf cart, we also provide many optional accessories
.
| Item | Option description | Item | Option description |
| 1 | E-key | 11 | 2-point seatbelt |
| 2 | Hinged windshield | 12 | Battery water refill system |
| 3 | Laminated windshield with wiper | 13 | Digital meter |
| 4 | Steel brush guard | 14 | EM brake |
| 5 | Front steel basket | 15 | Four wheel disc brake |
| 6 | Inner rear view mirror | 16 | Carlisle 205/50-10tyre with10inch wheel |
| 7 | Side rear view mirror | 17 | Ice box |
| 8 | Enclosure | 18 | Sand bottle |
| 9 | Sunshine cover | 19 | Sand rake |
| 10 | Golf bag cover | 20 | Ball washer |
Packing & Shipping
Excar golf cart will be packed in steel crate
| Model | Dimension(mm) | 20” container | 40” container | |||
| A1S2 | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield |
| 2641*1219*1727 | 2641*1219*1250 | 4 units | 8units | 10units | 20units |
|
a) LCL shipment Packing:
roof move-off packing, steel frame , cartoon paper cover.
b)FCL shipment Packing:
packed by plastic foam & plastic film
